RAINBIRD IRRIGATION CONTROLER 8 STATION INDOOR ESP-RZX8

FEATURES

• Simple user interface is easy to explain and presents every controller feature on a single screen
• Requires only two mounting screws
• Large LCD display with easy to navigate user interface
• Weather Sensor input with software override
• Master valve/pump start circuit
• Non-Volatile (100-year) program memory
• Programmable under battery power
• Zone-based scheduling allows for independent schedules assigned to each zone (Run times, Start Times and watering days are customizable by zone)
• Contractor Rapid Programming™ automatically copies the start times and watering days from zone 1 to all remaining zones at initial set up
• 6 independent Start Times per zone
• 4 Watering Days options by zone: custom days of the week, Odd calendar days, EVEN calendar days, Cyclic (every 1 – 14 days)
• Manually water ALL or SINGLE zone on demand
• Electronic diagnostic circuit breaker
• Contractor Rapid Programming™ and “copy previous Zone” for faster initial set up
• Contractor Default™ save / restore
• Weather Sensor bypass
• Weather Sensor bypass by Zone
• LNK WiFi Ready
• Controller Hardware
• Plastic wall-mount case
• 8  station units
• 2 x AAA batteries for time and date backup

SPECIFICATIONS

• Station timing: 0 to 199 min
• Seasonal Adjust: -90% to +100%
• Independent schedule per zone
• 6 Start Times per zone
• Program Day Cycles include Custom days of the week, Odd, Even, & Cyclical dates
• Manual SINGLE zone
• Manual ALL zones
• Electrical Specifications
• International models: 230 VAC ± 10%, 50Hz
• Output: 24 VAC 650mA
• Power back-up: 2 x AAA batteries maintain time and date while nonvolatile memory maintains the programming
• 2 Years warranty

Simple-To-Program Irrigation Indoor Controller: 8 stations.

• With LNK WiFi compatibility
• The ESP-RZXe Controller provides zone based set up that is easier to understand by untrained users.
• Provides flexible scheduling features that make the controller ideal for a wide variety of applications including residential and light commercial irrigation systems.

Easy to Use

• The ESP-RZXe Controller was designed with ease of use in mind.
• Zone-based scheduling allows every valve to be scheduled independently; no more explaining “programs” to end users, virtually eliminating call-backs.
• The large LCD display shows all of the programming for each zone at the same time.
• The simple graphic-based user interface is easy to explain and presents every controller feature at your fingertips

LNK WiFi Ready

• Combined with Rain Bird’s LNK WiFi Module (sold separately), you can receive internet-based weather data that adjusts irrigation schedules on a daily basis for up to 30% water savings.
